Technical data
型号LT-RTF15F
Detial NameFixed Short Arm -
Capacity1200 kg
Load Center650 mm
Roll Range410-1300 mm
Model No.RTF15F-013A -
Mounting ClassISO 2A -
Mounting Angle0° -
Long Arm Length864 mm
Short Arm Length658 mm
Arm Thickness- mm
Contact Pad Size850*300 mm
Vertical Center of Gravity348 mm
Horizontal Center of Gravity276 mm
Weight395 kg
Effective Thickneess144 mm
