Technical data
型号LT-RTP24G
Detial NamePositioned Short Arm -
Capacity2200 kg
Load Center575 mm
Roll Range200-1150 mm
Model No.RTP24G-001B -
Mounting ClassISO 3A -
Mounting Angle0° -
Long Arm Length820 mm
Short Arm Length550 mm
Arm Thickness40 mm
Contact Pad Size1300*300 mm
Vertical Center of Gravity360 mm
Horizontal Center of Gravity302 mm
Weight650 kg
Effective Thickneess232 mm
