Technical data
型号LT-BCS20E
Detial NameSideshifting -
Capacity1900 kg
Load Center500 mm
Model No.BCS20E-106A -
Mounting ClassISO 2A -
Opening Range450-1730 mm
Arm Length991 mm
Arm Height418 mm
Arm Thickness71 mm
Frame Width1040 mm
Vertical Center of Gravity202 mm
Horizontal Center of Gravity269 mm
Weight387 kg
Effective Thickneess128 mm
Due to continuous technological innovation, product configurations and technical parameters are subject to change without prior notice. All specifications and configurations are for reference only. In case of any doubt, please confirm with our international trade sales team. The formal signed business contract shall prevail.
