Technical data
型号LT-CKS30D
Detial Name2 D -Swing -
Capacity2700 kg
Load Center450 mm
Model No.CKS30D-090B -
Mounting ClassISO 3A -
Opening Range530-1860 mm
Arm Length900 mm
Arm Height210 mm
Arm Thickness234 mm
Frame Width1016 mm
Vertical Center of Gravity183 mm
Horizontal Center of Gravity267 mm
Weight545 kg
Effective Thickneess194 mm
Due to continuous technological innovation, product configurations and technical parameters are subject to change without prior notice. All specifications and configurations are for reference only. In case of any doubt, please confirm with our international trade sales team. The formal signed business contract shall prevail.
