Technical data
型号LT-DTS20D
Detial Name4 Drum Sideshifting -
Capacity1600 kg
Load Center600 mm
Model No.DTS20D-017A -
Mounting ClassISO 2A -
Opening Range460-1690 mm
Arm Length1060 mm
Arm Height800 mm
Arm Thickness150 mm
Frame Width940 mm
Vertical Center of Gravity228 mm
Horizontal Center of Gravity374 mm
Weight524 kg
Effective Thickneess144 mm
Due to continuous technological innovation, product configurations and technical parameters are subject to change without prior notice. All specifications and configurations are for reference only. In case of any doubt, please confirm with our international trade sales team. The formal signed business contract shall prevail.
