Technical data
型号LT-RCF33G
Detial NameFixed Short Arm -
Capacity3500 kg
Load Center650 mm
Roll Range425-1300 mm
Model No.RCF33G-001B -
Mounting ClassISO 3A -
Mounting Angle0° -
Long Arm Length876 mm
Short Arm Length574 mm
Arm Thickness45 mm
Contact Pad Size1000*240 mm
Vertical Center of Gravity435 mm
Horizontal Center of Gravity271 mm
Weight764 kg
Effective Thickneess210 mm
Due to continuous technological innovation, product configurations and technical parameters are subject to change without prior notice. All specifications and configurations are for reference only. In case of any doubt, please confirm with our international trade sales team. The formal signed business contract shall prevail.
