Technical data
型号LT-RCP24G
Detial NamePositioned Short Arm -
Capacity2200 kg
Load Center575 mm
Roll Range200-1150 mm
Model No.RCP24G-001A -
Mounting ClassISO 2A -
Mounting Angle0° -
Long Arm Length790 mm
Short Arm Length520 mm
Arm Thickness40 mm
Contact Pad Size850*240 mm
Vertical Center of Gravity274 mm
Horizontal Center of Gravity248 mm
Weight610 kg
Effective Thickneess201 mm
Due to continuous technological innovation, product configurations and technical parameters are subject to change without prior notice. All specifications and configurations are for reference only. In case of any doubt, please confirm with our international trade sales team. The formal signed business contract shall prevail.
