Diesel Road Roller
LTC200
3800 mmWheelbase
20000/30000 (unballasted/ballasted) kgOperating Mass
125 kWEngine Power
Key Features
Equipped with a Cummins 6BTA5.9 diesel engine, the roller delivers high reliability, excellent fuel economy, and low noise for efficient and cost-effective operation.
Some of the product features listed above involve optional configurations. Please confirm the specific configuration with our international sales team.
Technical data
型号LTC200
Overall Length4950 mm
Overall Width2750 mm
Overall Height3240 mm
Wheelbase3800 mm
Operating Mass20000/30000 (unballasted/ballasted) kg
Engine Power125 kW
Engine ModelCummins 4BTA5.9 /
Travel Speed10 (max.) km/h
Turning Radius8000 (min.) mm
Gradeability30 %
Compaction Width2790 mm
Tyre Quantity (Front + Rear)5+6 /
Due to continuous technological innovation, product configurations and technical parameters are subject to change without prior notice. All specifications and configurations are for reference only. In case of any doubt, please confirm with our international trade sales team. The formal signed business contract shall prevail.
