Electric Pallet Stacker
FEP40
4000 kgRated Capacity
600 mmLoad Center
110 mmLift Height
Key Features
The compact vehicle design and small turning radius enable efficient handling and operation in narrow spaces.
Technical data
型号FEP40
Power TypeElectric /
Operation TypeStanding / platform /
Rated Capacity4000 kg
Load Center600 mm
Wheelbase1480 mm
Service Weight (with Battery)1085 kg
Wheels TypePolyurethane /
Driving Wheel Size230×75 mm
Load Wheel Size85×110 mm
Balance Wheel Size130×80 mm
Lift Height110 mm
Lowered Fork Height100 mm
Overall Length2065 mm
Overall Length (with Platform)2570 mm
Overall Width876 mm
Fork Length1150 mm
Fork Outside Width750 mm
Fork Inside Width250 mm
Fork Thickness78 mm
Min. Ground Clearance5 mm
Aisle Width (1000×1200 Pallet, Across Forks)2440 mm
Min. Turning Radius1770 mm
Min. Turning Radius (with Platform)2190 mm
Travel Speed (Loaded/Unloaded)5/5.5 km/h
Lift Speed (Loaded/Unloaded)30/50 mm/s
Lowering Speed (Loaded/Unloaded)57/57 mm/s
Max. Gradeability (Loaded/Unloaded)\ / \ %
Drive Motor Power2.2 kW
Lift Motor Power2.2 kW
Battery Voltage / Capacity24/210 V/Ah
Battery Weight195 kg
Drive Motor TypeAC motor /
Lift Motor TypeDC motor /
