Electric Pallet Stacker

FEP50

Name: FEP50 仓储车-FEP50
Brand: LTMG

5000 kgRated Capacity

600 mmLoad Center

110 mmLift Height

Request an inquiry

Key Features

The compact vehicle design and small turning radius enable efficient handling and operation in narrow spaces.

Some of the product features listed above involve optional configurations. Please confirm the specific configuration with our international sales team.

Technical data

型号FEP50

Power TypeElectric /

Operation TypeStanding / platform /

Rated Capacity5000 kg

Load Center600 mm

Wheelbase1480 mm

Service Weight (with Battery)1085 kg

Wheels TypePolyurethane /

Driving Wheel Size230×75 mm

Load Wheel Size85×110 mm

Balance Wheel Size130×80 mm

Lift Height110 mm

Lowered Fork Height100 mm

Overall Length2065 mm

Overall Length (with Platform)2570 mm

Overall Width876 mm

Fork Length1150 mm

Fork Outside Width750 mm

Fork Inside Width250 mm

Fork Thickness78 mm

Min. Ground Clearance5 mm

Aisle Width (1000×1200 Pallet, Across Forks)2440 mm

Min. Turning Radius1770 mm

Min. Turning Radius (with Platform)2190 mm

Travel Speed (Loaded/Unloaded)5/5.5 km/h

Lift Speed (Loaded/Unloaded)30/50 mm/s

Lowering Speed (Loaded/Unloaded)57/57 mm/s

Max. Gradeability (Loaded/Unloaded)\ / \ %

Drive Motor Power2.2 kW

Lift Motor Power2.2 kW

Battery Voltage / Capacity24/210 V/Ah

Battery Weight195 kg

Drive Motor TypeAC motor /

Lift Motor TypeDC motor /

Due to continuous technological innovation, product configurations and technical parameters are subject to change without prior notice. All specifications and configurations are for reference only. In case of any doubt, please confirm with our international trade sales team. The formal signed business contract shall prevail.
