Key Features
High-quality mast steel provides excellent rigidity and long-lasting durability.
Some of the product features listed above involve optional configurations. Please confirm the specific configuration with our international sales team.
Technical data
型号HS30
Power TypeManual /
Operation TypeWalkie /
Rated Capacity3000 kg
Load Center500 mm
Service Weight310 kg
Lowered Mast Height2086 mm
Overall Height (Mast Lowered)2086 mm
Lift Height1600 mm
Fork Lowered Height90 mm
Overall Length1360 mm
Overall Width765 mm
Fork Dimensions30×100×1070 / 60×142×1070 mm
Distance Between Forks550/660 mm
Minimum Ground Clearance25 mm
Turning Radius1200 mm
Lifting Speed (Laden/Unladen)9.5/10.5 mm/s
Lowering Speed (Laden/Unladen)Manual mm/s
Due to continuous technological innovation, product configurations and technical parameters are subject to change without prior notice. All specifications and configurations are for reference only. In case of any doubt, please confirm with our international trade sales team. The formal signed business contract shall prevail.
