Key Features
Equipped with a famous-brand engine to ensure stable quality and outstanding performance.
Some of the product features listed above involve optional configurations. Please confirm the specific configuration with our international sales team.
Technical data
型号4HL90
Operating Weight960 kg
Engine BrandKUBOTA /
Engine ModelD1105 /
Engine Power22 kW
Rated Voltage230 V
Fuel Tank Capacity110 L
Continuous Operating Time65 h
Lamp TypeRegular metal halide /
Lamp Power × Quantity1000 × 4 W
Mast Height9 m
Wind Resistance20 m/s
Overall Length4360 mm
Overall Width1430 mm
Overall Height1450 mm
Engine TypeThree cylinder, water-cooled, four stroke /
Engine Speed1500/1800 rpm
Combustion SystemE-TVS /
Generator Protection GradeIP23 /
Luminous Flux440000 lm
Mast Lifting MethodHand lift /
Mast Section Count3 section
Generator Start MethodKey starting /
Noise Level72 at 7 meters away dB(A)
Suspension and BrakesLeaf spring suspension & alone without brake /
DrawbarAdjustable lever with telescopic adjustment guide wheel /
Tire and Rim Size14 /
Maximum Towing Speed100 km/h
Due to continuous technological innovation, product configurations and technical parameters are subject to change without prior notice. All specifications and configurations are for reference only. In case of any doubt, please confirm with our international trade sales team. The formal signed business contract shall prevail.
