Key Features
The engine of FD15 intake adopts a high independent channel to prevent dust inhalation and effectively increase the engine intake volume to make the engine burn more fully.
Some of the product features listed above involve optional configurations. Please confirm the specific configuration with our international sales team.
Technical data
ModelFD15
Power TypeDiesel —
Rated Capacity1500 kg
Load Center500 mm
Lift Height3000 mm
Fork Size920×120×35 mm
Mast Tilt Angle (F/R)6/12 Deg
Turning Radius2055 mm
Ground Clearance110 mm
Front Overhang410 mm
Max. Gradeability20 %
Wheelbase1400 mm
Overall Weight2820 kg
Total Length without Fork2285 mm
Overall Width1086 mm
Mast Lowered Height1995 mm
Mast Extended Height3940 mm
Overhead Guard Height2040 mm
Max Travel Speed (Full load)15 km/h
Max Lift Speed (Full load)450 mm/s
Front Tyres6.50-10-12PR —
Rear Tyres5.00-8-10PR —
Battery12/80 V/Ah
Engine ModelC240 / NC485BPG-508 —
Engine Power35.4/2500 / 30/2600 kW/rpm
Engine ManufacturerISUZU / XINCHAI —
Max. Torque / Speed137.7/1800 / 131/1700-1900 N·m/rpm
No. of Cylinder4/4 —
Bore × Stroke86×102 / 85×100 mm
Displacement2369 / 2270 cc
Fuel Tank Capacity45 L
Transmission TypeHydraulic —
Transmission Stage (FWD/RVS)1/1 —
Due to continuous technological innovation, product configurations and technical parameters are subject to change without prior notice. All specifications and configurations are for reference only. In case of any doubt, please confirm with our international trade sales team. The formal signed business contract shall prevail.
