Key Features
Uses a high, independent channel to block dust and increase airflow, ensuring more complete fuel combustion.
Technical data
型号FD50
Power TypeDiesel —
Rated Capacity5000 kg
Load Center500 mm
Lift Height3000 mm
Fork Size1070×150×50 mm
Mast Tilt Angle (F/R)6°/12° Deg
Turning Radius2910 mm
Ground Clearance150 mm
Front Overhang579 mm
Max. Gradeability20 %
Wheel Base2100 mm
Overall Weight6700 kg
Total Length without Fork3260 mm
Overall/Total Width1460 mm
Mast Lowered Height2270 mm
Mast Extended Height4165 mm
Overhead Guard Height2340 mm
Max Travel Speed (Empty load)25 km/h
Max Lift/Lifting Speed (Full load)380 mm/s
Front Tyres300-15-18 PR —
Rear Tyres7.00-12-12 PR —
Battery(12/80) × 2 V/Ah
Engine Model6BG1-02 —
Engine Power82.4/2000 kW/rpm
Min. intersecting aisle2920 mm
Engine ManufactureISUZU —
Engine Rated Torque4168/1500 N·m/rpm
No. of Cylinder6 —
Bore×Stroke105 × 125 mm
Displacement6494 cc
Fuel Tank Capacity130 L
Transmission TypeHydraulic —
Transmission Stage (FWD/RVS)46054 —
Operating Pressure for Attachment18 Mpa
